929654

ElectroGreen®

greener alternative

Isopropyl Alcohol substitute for electronics, bio-based

조직 및 계약 가격을 보려면 로그인를 클릭합니다.

크기 선택

보기 변경

제품정보 (DICE 배송 시 비용 별도)

NACRES:
NA.05
UNSPSC Code:
12190000
기술 서비스
도움이 필요하신가요? 저희 숙련된 과학자 팀이 도와드리겠습니다.
도움 문의

Quality Level

200

description

Electronic Solvents, Relative Evaporation rate: 1.24


Hansen solubility parameters: SPd = 7.7; SPp = 4.2; SPh = 8.8. , for electronic purposes

assay

≥ 99.0% (GC)

form

liquid

greener alternative product characteristics

Design for Energy Efficiency
Use of Renewable Feedstocks
Learn more about the Principles of Green Chemistry.

impurities

≤0.09 wt. % Acidity (as lactic acid), ≤0.5 wt. % Water (Karl Fischer), ≤1 ppm As, Cr, Cd, Cu, Hg, Mn, Ni, Pb, Zn, trace (ICP, each)

evapn. residue

≤0.05%

color

clear

viscosity

9.8  cP(20 °C)

density

0.8351 at 25 °C (specific gravity)

greener alternative category

Enabling

storage temp.

2-30°C

General description

ElectroGreen® solvents—our bio-based alternatives that are meticulously engineered to meet the stringent requirements of electronics and energy applications, offering a solution to replace fossil-based solvents.
Our tailored products offer:
  • High purity (GC)
  • Low residue in evaporation (RESE)
  • Low metal content (ICP)
  • Low water content (KF)
  • Low acidity
  • Low toxicity and VOC
  • Accessible cost
This ElectroGreen® solvent is made of bio-based (corn/beets-derived)safer alternatives to replace synthetic propanol/IPA fossil-based solvent with specifications tailored for electronics and energy applications. All our ElectroGreen® solvents line are derived from a renewable resource (verified through C14 ASTM D6866-16 testing). We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. Click here for more details.

This solvent blend consists of ethanol 70-90%, Ethyl lactate 20-30%, ethyl acetate 1-5%.

Increase safety and use less chemicals in semiconductor manufacturing thereby reducing costs

Application

Our Isopropyl Alcohol substitute is a blend of bio-based solvents that provide excellent cleaning properties on electronics: dries quickly, and provides a clean, non-residue surface. Ideal for dilution in a hot water spray at time of use. Suitable replacement for Isopropyl Alcohol (IPA).

Preparation Note

To ensure low water content, handle under inert conditions. Product should be refrigerated upon receipt.

Legal Information

ElectroGreen is a registered trademark of Merck KGaA, Darmstadt, Germany

Still not finding the right product?

Explore all of our products under

signalword

Danger

Hazard Classifications

Eye Dam. 1 - Flam. Liq. 2 - STOT SE 3

target_organs

Respiratory system

저장 등급

3 - Flammable liquids

wgk

WGK 1

flash_point_f

52.0 °F

flash_point_c

11.1 °C
