1.07223

1,10-Phenanthroline chloride monohydrate

GR for analysis and redox indicator [reagent for iron(II)] Reag. Ph Eur

Synonym(s):

1,10-Phenanthroline chloride monohydrate, o-Phenanthroline hydrochloride monohydrate

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):
C12H9ClN2 · xH2O
CAS Number:
18851-33-7
Molecular Weight:
216.67 (anhydrous basis)
UNSPSC Code:
12352107
EC Index Number:
223-325-1
NACRES:
NA.21
MDL number:
MFCD00150061
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

agency

reag. Ph. Eur.

Quality Level

100

form

solid

potency

132 mg/kg LD50, oral (Rat)

mp

215-220 °C (decomposition)

bulk density

370 kg/m3

storage temp.

2-30°C

SMILES string

[Cl-].[n+H]1c2c3ncccc3ccc2ccc1.O

InChI

1S/C12H8N2.ClH.H2O/c1-3-9-5-6-10-4-2-8-14-12(10)11(9)13-7-1;;/h1-8H;1H;1H2

InChI key

NDLHUHRGAIHALB-UHFFFAOYSA-N

Analysis Note

  • Assay (alcalimetric, calculated on anhydrous substance): ≥ 99.5 %
  • Identity (IR-spectrum): passes test
  • Melting point: about 215 °C, with decomposition
  • Substances insoluble in water: passes test
  • Sulfated ash: ≤ 0.2 %
  • Water (according to Karl Fischer): 6.5 - 8.5 %
  • Suitability as indicator: passes test
  • Sensitivity test (at Iron II ions): passes test

pictograms

Skull and crossbonesEnvironment
GHS06,GHS09

signalword

Danger

Hazard Classifications

Acute Tox. 3 Oral - Aquatic Acute 1 - Aquatic Chronic 1

flash_point_f

Not applicable

flash_point_c

Not applicable

hcodes

H301,H410

Storage Class

6.1C - Combustible acute toxic Cat.3 / toxic compounds or compounds which causing chronic effects

Certificates of Analysis (COA)

Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Protocols

Determination of Silver in Water and Wastewater: Photometric Determination Using Phenanthroline Method and Eosin Y

The article describes the sample preparation and photometric determination of silver concentration in water samples using Spectroquant® photometers and test kits.

Global Trade Item Number

SKUGTIN
107223001004022536088389
107223010004022536088396
