PEDOT:PSS

greener alternative

conductive inkjet ink, 0.8% aqueous dispersion

Synonym(s):

Orgacon™ IJ-1005, PEDOT:PSS, Poly(2,3-dihydrothieno-1,4-dioxin)-poly(styrenesulfonate)

Sign Into View Organizational & Contract Pricing

Select a Size

About This Item

MDL number:
MFCD07371079
UNSPSC Code:
12352103
NACRES:
NA.23

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate), 0.8% in H2O, conductive inkjet ink

description

Electrodes

Quality Level

100

form

liquid

contains

1-5% Ethanol
5-10% Diethylene glycol

greener alternative product characteristics

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

sustainability

Greener Alternative Product

concentration

0.8% in H2O

sheet resistance

110 Ω/sq

refractive index

n20/D 1.340

pH

1.5-2.5

viscosity

7-12 cP(22 °C)

density

0.985 g/mL at 25 °C

greener alternative category

, Enabling

storage temp.

2-8°C

Looking for similar products? Visit Product Comparison Guide

Related Categories

General description

Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate) (PEDOT:PSS) is an organic semiconductor wherein conjugated PEDOT is doped with sulfonated PSS, which acts as a counter ion. PEDOT is responsible for the conduction mechanism and the hydrated colloidal solution formed by PSS.
PEDOT:PSS has high electrical conductivity and good oxidation resistance, the properties which make it suitable for electromagnetic shielding and noise suppression. Thus, the polymeric film formed possesses high transparency throughout the visible light spectrum and even in near IR and near UV regions, displaying virtually 100% absorption from 900-2,000 nm. No absorption maximum from 400-800 nm was observed.
We are committed to bringing you Greener Alternative Products, which adhere to one or more of the 12 Principles of Green Chemistry. This product is used in energy conversion and storage, thus has been enhanced for energy efficiency. Click here for more information.

Application

PEDOT:PSS acts as an intrinsically conductive polymer, which can be coated on a variety of substrates and nanoparticles like fullerenes (C60) for the low-cost printing of electronics and optoelectronics based applications. Conductive hydrogels can be prepared by using PEDOT:PSS with polyethylene glycol-diacrylate, which can be potentially used in tissue engineering.
Virtually 100% absorption from 900-2,000 nm. No absorption maximum from 400-800 nm. Conductive polymer blend.

Legal Information

Product of Agfa-Gevaert N.V.
Orgacon is a trademark of Agfa-Gevaert N.V.

Storage Class

10 - Combustible liquids

wgk_germany

WGK 2

flash_point_f

Not applicable

flash_point_c

Not applicable

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
STBK5588
STBK5589
STBJ9356
STBJ3111
MKCK0489

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Adrien Pierre et al.
Advanced materials (Deerfield Beach, Fla.), 26(32), 5722-5727 (2014-06-20)
A combination of surface energy-guided blade coating and inkjet printing is used to fabricate an all-printed high performance, high yield, and low variability organic thin film transistor (OTFT) array on a plastic substrate. Functional inks and printing processes were optimized
EFFECTIVENESS OF ANNEALING TREATMENT AND POLYMER BLENDS ON IV CHARACTERISTSICS OF POLYMER SOLAR CELL.
Rosa E and Shobih S
Reaktor, 14(4), 261-266 (2014)
Solar cells made from polymers containing Dithieno [3, 2-b: 2', 3'-d] pyrrole with different side chain lengths
Gong C, et al.
Solar Energy Mat. and Solar Cells, 95(3), 969-973 (2011)
Structure and electronic properties of poly(3,4-ethylenedioxythiophene) poly(styrene sulfonate) prepared under ultrasonic irradiation
Posudievsky OYu, et al.
Synthetic Metals, 195, 335-339 (2014)
SURPRISING IMPACT OF SMALL ELECTRIC AND MAGNETIC FIELDS ON CONDUCTING POLYMERS
Epstein AJ, et al.
Polymer Preprints (American Chemical Society, Division of Polymer Chemistry), 48(1), 119-119 (2007)
View All Related Papers

Articles

Graphene Inks for Electronics

Functional materials for printed electronics applications enable flexible displays, RFID tags, and biomedical sensors.

Conducting Polymer Device Applications

The application of conducting polymers at the interface with biology is an exciting new trend in organic electronics research.

Conductive Polymers for Advanced Micro- and Nano-fabrication Processes

Conducting polymers such as polyaniline, polythiophene and polyfluorenes are now much in the spotlight for their applications in organic electronics and optoelectronics.

Substrate and Conductor Materials Towards More Sustainable Electronics

The European Green Deal and Circular Economy Action Plan address resource challenges with eco-products and circulatory work, while the revised EU Ecodesign Directive promotes e-waste reduction and natural resource value reform. This review examines renewable substrates and conductive materials for flexible electronics.
