735167

Fluorine doped tin oxide coated glass slide

greener alternative

L × W × thickness 300 mm × 300 mm × 2.2 mm, surface resistivity ~7 Ω/sq

Synonym(s):

FTO glass

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

UNSPSC Code:
12352103
EC Number:
242-159-0
NACRES:
NA.23
Material:
coating (Fluorine doped tin oxide)
Packaging:
1 ea of
Manufacturer/tradename:
Sigma-Aldrich
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Quality Level

100

material

coating (Fluorine doped tin oxide)

description

Haze: 5%, Substrates and Prefab Devices

composition

SnO2/F

manufacturer/tradename

Sigma-Aldrich

packaging

1 ea of

greener alternative product characteristics

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

sustainability

Greener Alternative Product

surface resistivity

~7 Ω/sq

L × W × thickness

300 mm × 300 mm × 2.2 mm

transmittance

80-82% (visible)

greener alternative category

Enabling

General description

The coating thickness of Fluorine doped tin oxide on glass slide is ∼ 550 nm. The glass has a refractive index of ∼ 1.52 and the SnO2:F coating is ∼ 1.85.
We are committed to bringing you Greener Alternative Products that adhere to one of the four categories of Greener Alternatives. This is an enabling product that enhances the performance of perovskite fuel cells, facilitating high solar energy conversion and contributing to more efficient energy solutions. Click here for more information.

Application

Fluorine doped tin oxide coated glass slide (FTO glass) can be used as a substrate for the fabrication of dye sensitized solar cells (DSSCs) and photovoltaic cells (PVs).

Still not finding the right product?

Explore all of our products under Fluorine doped tin oxide coated glass slide

Storage Class

13 - Non Combustible Solids

wgk

WGK 2

flash_point_f

Not applicable

flash_point_c

Not applicable
